Domaine d’utilisation
Toutes applications en construction mécanique.
Caractéristiques techniques
Conforme à la DIN 6303
Version acier :
En C22 selon norme NF-EN 10083
Finition bruni ou (option) zingué blanc
Version acier Inoxydable :
Acier inoxydable A4 selon norme NF EN 10 088
Finition passivé
| Version | D1 | D2 | D3 | D4 | A | B | C | Référence Colin Milas | |
| Acier | Acier inoxydable | ||||||||
| Acier C22 | M6 | 16 | 24 | 14 | 8 | 4 | 4 | 41-05-006-F | 41-05-006-IN |
| Acier C22 | M8 | 20 | 30 | 17 | 10 | 5 | 5 | 41-05-008-F | 41-05-008-IN |
| Acier C22 | M10 | 28 | 36 | 20 | 12 | 6 | 6 | 41-05-010-F | 41-05-010-IN |
| Acier C22 | M12 | 32 | 40 | 24 | 16 | 8 | 8 | 41-05-012-F | 41-05-012-IN |
| Acier C22 | M16 | 40 | 50 | 32 | 20 | 12 | 12 | 41-05-016-F | 41-05-016-IN |
| Acier C22 | M20 | 48 | 60 | 40 | 24 | 16 | 16 | 41-05-020-F | 41-05-020-IN |
